Product Details
Features
Overall encapsulated waterproof IP67 | Top buckle micro convex cover self-cleaning | Bright and stable lamp bead
Glue, steel wire and base screw installation | Transparent, milky white cover is optional
It is widely used for single building outlines such as commercial and residential build ings, municipal buildings, bank buildings, urban streets, rivers, bridges, urban commer cial complexes, star hotels, or multi building linkage media displays
Technical parameters
| Item | XH-H5012P24 |
|---|---|
| Product Model | XH-H5012P24 |
| Operating Voltage | DC24V |
| Light Source Color | RGB |
| Power | 3W |
| Control Mode | DMX512 |
| Luminous Flux | 62LM (RGB full brightness) |
| Dimension | Ø50×18.5mm |
| Housing Material | PC |
| Unit Weight | 36g |
| Beam Angle | 120° |
| Operating Temperature | -20℃ ~ +60℃ |
| Average Lifespan | ＞30000h |
| Safety Protection | |
| Ingress Protection | IP67 |
| Flame Retardant Rating | V-0 |
| Electrical Safety Class | Class III |
| Impact Resistance | IK10 |
| Salt Spray Test | Salt corrosion resistant |
