Product Details
Features
Small and easy to install | Flame retardant PC anti UV | Glue pouring protection IP67
Pressure resistance | good weather resistance | Opening, profile, steel wire base and screw installation
It is widely used for the outlines of single buildings such as commercial and residential buildings, municipal buildings, bank buildings, urban streets, rivers, bridges, urban commercial complexes, star hotels, or multiple buildings linked with media displays; High cost performance light source for large and medium-sized advertising signs.
Technical parameters
| Item | XH-G3006M12 |
|---|---|
| Product Model | XH-G3006M12 |
| Operating Voltage | DC12V |
| Light Source Color | R/G/B/2000-6500K / Other Custom Colors |
| Power | 0.6W |
| Control Protocol | Single Color On-Off |
| Luminous Flux | 30LM (6500K) |
| Dimension | Ø29.65×11.21mm |
| Housing Material | PC |
| Weight Per Lamp | 13g |
| Beam Angle | 120° |
| Operating Temperature | -20℃ ~ +60℃ |
| Average Lifespan | ＞30000h |
| Safety Protection | |
| Ingress Protection | IP67 |
| Flame Class | V-0 |
| Electrical Safety Class | Class III |
| Impact Resistance | IK10 |
| Salt Spray Test | Salt Resistance |
