Product Details
Features
Large wire diameter power supply | ultra long distance energy efficiency and stability | less wiring and material saving
Screw, steel wire base, adhesive, profile | Overall encapsulated waterproof IP67 | Optical mask anti glare | Pure light color
It is often used in the outdoor super high-rise commercial and residential building body contour and texture lines, rivers and lakes, bridge wings and other places where lamps need to be arranged for a long distance, saving labor and materials
Technical parameters
| Item | XH-K4006M36 | XH-K4006P36 | XH-K4006W36 |
|---|---|---|---|
| Product Model | XH-K4006M36 | XH-K4006P36 | XH-K4006W36 |
| Operating Voltage | DC36V | DC36V | DC36V |
| Light Source Color | R/G/B/Y/W (1800-6500K) | RGB | RGBW |
| Power | 1.5W | 1.5W | 2W |
| Control Protocol | Constant On / Single Color On-Off | DMX512 | DMX512 |
| Luminous Flux | 15LM (6500K) | 10LM (RGB Full Color) | 10LM (RGB Full Color) |
| Dimension | Ø45×60mm | Safety Protection | |
| Housing Material | PC | Ingress Protection: IP67 | |
| Weight Per Lamp | 20g | Flame Class: V-0 | |
| Beam Angle | 120° | Electrical Safety Class: Class III | |
| Operating Temperature | -20℃ ~ +60℃ | Impact Resistance: IK10 | |
| Average Lifespan | ＞30000h | Salt Spray Test: Salt Resistance |
