Features
Transparent | Modular | Lightweight | Self cooling | Protection IP67
Exclusive patent | Multiple density options | Clasp splicing | Wire fixation | Roll and bag transportation
It is commonly used for making lamps for solid wall, steel structure, glass curtain wall plane or curved display screen of large indoor and outdoor buildings; Cultural tourism promotion, commercial advertising, city business card promotion and other large, medium and large display media.
Technical parameters
| Item |
XH-FXL20006 |
|
XH-FXL20006S24 |
|
| Product Model |
XH-FXL20006 |
|
XH-FXL20006S24 |
|
| Operating Voltage |
DC15V |
|
DC24V |
|
| Light Source Color |
RGB |
|
RGB |
|
| Control Protocol |
DMX512 |
|
UCS9812 |
|
| Pixel Density |
30*20pcs |
30*16pcs |
30*12pcs |
30*10pcs |
| Pixel Pitch |
33.3*50mm |
33.3*62.5mm |
33.3*83.3mm |
33.3*100mm |
| Max Power |
180W |
144W |
108W |
90W |
| Screen Weight |
6.5kg |
5.2kg |
3.8kg |
3.1kg |
| Safety Protection |
|
|
|
|
| Beam Angle |
160° |
Ingress Protection |
IP67 |
|
| Operating Temperature |
-20℃ ~ +60℃ |
Flame Class |
V-0 |
|
| Average Lifespan |
＞30000h |
Salt Spray Test |
Salt Resistance |
|
| Electrical Safety Class |
Class III |
Impact Resistance |
IK10 |
|
