Product Details
Features
Transparent | Modular | Lightweight | Self cooling | Protection IP67
Exclusive patent | Multiple density options | Clasp splicing | Wire fixation | Roll and bag transportation
It is commonly used for making lamps for solid wall, steel structure, glass curtain wall plane or curved display screen of large indoor and outdoor buildings; Cultural tourism promotion, commercial advertising, city business card promotion and other large, medium and large display media.
Technical parameters
| Item | Parameter |
|---|---|
| Product Model | XH-HXK3003 |
| Operating Voltage | DC12V |
| Light Source Color | RGB/RGBW |
| Power per Pixel | 0.75/1W |
| Control Protocol | DMX512 |
| Pixel Density | 100pcs |
| Pixel Pitch | 100mm |
| Max Power | 75/100W |
| Screen Weight | 2.7kg |
| Housing Material | Flame-retardant PC bracket + silicone |
| Beam Angle | 160° |
| Operating Temperature | -20℃ ~ +60℃ |
| Average Lifespan | ＞30000h |
| Safety Protection | |
| Ingress Protection | IP67 |
| Flame Class | V-0 |
| Electrical Safety Class | Class III |
| Impact Resistance | IK10 |
| Salt Spray Test | Salt Resistance |
