Product Details
Features
Far power supply distance | less wiring | less materials | installation of profile, steel wire and base screw waterproof IP67
Pure light color | PC material | convex cover design, self-cleaning | Profile, steel wire base and screw installation
It is widely used in high-end technical, scientific and environment-friendly night scene lighting projects such as commercial and residential buildings, municipal buildings, bank buildings, urban streets, rivers, bridges, urban commercial complexes, star hotels, etc
Technical parameters
| Item | XH-K5012P24 | XH-K5012P24RGBW |
|---|---|---|
| Product Model | XH-K5012P24 | XH-K5012P24RGBW |
| Operating Voltage | DC24/36V | DC24/36V |
| Light Source Color | RGB | RGBW |
| Power | 3W | 4W |
| Control Mode | DMX512 | DMX512 |
| Luminous Flux | 45LM (RGB full brightness) | 45LM (RGB full brightness), 421lm(W) |
| Dimension | Ø50.8×17.66mm | Safety Protection |
| Housing Material | PC | Ingress Protection: IP67 |
| Unit Weight | 27g | Flame Retardant Rating: V-0 |
| Beam Angle | 120° | Electrical Safety Class: Class III |
| Operating Temperature | -20℃ ~ +60℃ | Impact Resistance: IK10 |
| Average Lifespan | ＞30000h | Salt Spray Test: Salt corrosion resistant |
