| Pixel pitch (mm) |
2.60416/5.20833 |
3.90625/3.90625 |
3.90625/7.8125 |
3.90625/7.8125 |
7.8125/7.8125 |
10.4166/10.4166 |
15.625/15.625 |
| Pixel Composition |
SMD2121/1921 |
SMD1515/1415 |
SMD2121/1921 |
SMD1921 |
SMD1921 |
SMD2727 |
SMD2727 |
| Brightness level |
1000/5000CD/m² |
1000/2000CD/m² |
600/2000CD/m² |
4500-5000CD/m² |
6000-7000CD/m² |
6000-8000CD/m² |
4500-5000CD/m² |
| Pixel density |
73728dot/m² |
65536dot/m² |
32768dot/m² |
32768dot/m² |
16384dot/m² |
9216dot/m² |
4096dot/m² |
| Transmittance |
≥40% |
≥55% |
≥55% |
≥55% |
≥55% |
≥70% |
≥75% |
| Enclosure Dimensions |
1000X1000X69mm |
1000X1000X69mm |
1000X1000X69mm |
1000X1000X69mm |
1000X1000X69mm |
1000X1000X69mm |
1000X1000X69mm |
| Enclosure Resolution |
384X192dot |
256X256dot |
256X128dot |
256X128dot |
128X128dot |
96X96dot |
64X64dot |
| Weight |
8.2kg/Panel |
8kg/Panel |
7.5kg/Panel |
7.5kg/Panel |
7.5kg/Panel |
7.5kg/Panel |
7.5kg/Panel |
| Protection Rating |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
| Operating Environment |
INDOOR |
INDOOR |
INDOOR |
INDOOR |
INDOOR |
INDOOR |
INDOOR |
| Viewing angle |
140°/140° |
140°/140° |
140°/140° |
140°/140° |
140°/140° |
140°/140° |
140°/140° |
| Visual range |
>3m |
>4m |
>4m |
>4m |
>7m |
>10m |
>15m |
| Gray scale |
14bit-16bit |
14bit-16bit |
14bit-16bit |
14bit-16bit |
14bit-16bit |
14bit-16bit |
14bit-16bit |
| Maximum Power |
680W/m² |
680W/m² |
340W/m² |
680W/m² |
680W/m² |
680W/m² |
680W/m² |
| Average power |
240W/m² |
240W/m² |
160W/m² |
260W/m² |
260W/m² |
260W/m² |
260W/m² |
| Refresh rate |
1920Hz/3840Hz |
1920Hz/3840Hz |
1920Hz/3840Hz |
1920Hz/3840Hz |
1920Hz/3840Hz |
1920Hz/3840Hz |
1920Hz/3840Hz |
| Scanning Method |
12S |
16S |
16S |
8S |
4S |
2S |
1S |
| Input power |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
AC100~240V, 50/60Hz |
| Control Method |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
Synchronous display with control PC by DVI |
| Supported Signal Input Types |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
Composite, S-Vido, Component, VGA, DVI, HDMI, HD_SDI |
| Temperature |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
-20°C~40°C (work), -20°C~60°C (store) |
| Humidity |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
35%~85% (work), 10%~90% (store) |
| Service life |
100,000 hours |
100,000 hours |
100,000 hours |
100,000 hours |
100,000 hours |
100,000 hours |
100,000 hours |
| Enclosure Material |
Aluminum profile |
Aluminum profile |
Aluminum profile |
Aluminum profile |
Aluminum profile |
Aluminum profile |
Aluminum profile |
